TP-LINK 5-Port Unmanaged 10G Multi-Gigabit Desktop / Rackmount Switch - (TL-SX105) TP-LINKTL-SX105

The TP-LINK TL-SX105 is a 5-Port, Unmanaged, 10G Multi-Gigabit, Desktop/Rackmountable Switch, designed to provide high-speed connectivity for various network environments. This switch supports speeds ranging from 100 Mbps to 10 Gbps, offering flexible and robust performance for demanding applications.

Its fanless design ensures silent operation and the steel case provides durability. The TL-SX105 is suitable for both desktop and rackmount installations, making it a versatile solution for enhancing network capabilities, without the need for complex configurations.

Specifications

• Model: TP-LINK TL-SX105
• Form Factor: Desktop/Rackmount
• Managed: No
• Number of Ports: 5
• Max RJ45 Transfer Rate: 10 Gbps
• Interfaces: 5 x 100Mbps/1Gbps/2.5Gbps/5Gbps/10Gbps Ports
• Auto-Negotiation: Yes
• Auto-MDI/MDIX: Yes
• Switching Capacity: 100 Gbps
• Packet Forwarding Rate: 2 Mb
• Mac Address Table: 32 K
• Jumbo Frame: 10 KB
• Transfer Method: Store and Forward
• Power Supply: External Power Adapter (Output: 12 VDC / 2.0 A)
• Max Power Consumption: 21.4 W
• Standards: IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, 802.3an, 802.3bz
• LED Indicators:

• System Power: 1
• Link/Act Indicators: 5 (1 indicator per port built into each RJ-45 port)
• Advanced Functions:
• Flow Control: 802.3X Flow Control
• Quality of Service (QoS): 802.1p/DSCP QoS
• Environmental:
• Operating Temperature: 0-40 ?C (32-104 ?F)
• Storage Temperature: -40-70 ?C (-40-158 ?F)
• Operating Humidity: 10-90% RH non-condensing
• Storage Humidity: 5-90% RH non-condensing
• Dimensions: Size: 226 x 131 x 35 mm
• Package Contents:
• 5-Port 10G Multi-Gigabit Switch
• Power Cord
• Installation Guide
• Rackmount Kit
• Rubber Feet
• Package Weight: 1.6100 kg
• Package Type: Retail
